Access Point TP-Link [EAP610-OUTDOOR] AX1800

Interface

1× Gigabit Ethernet (RJ-45) Port (Support 802.3at PoE and Passive PoE)

Processor & Memory

–

Frequency

2.4 GHz, 5 GHz

Wi-Fi Radio Specifications

802.11ax: 8 Mbps to 1201 Mbps (MCS0-MCS11, NSS = 1 to 2 HE20/40/80)
802.11ac: 6.5 Mbps to 867 Mbps (MCS0-MCS9, NSS = 1 to 2 VHT20/40/80)
802.11n: 6.5 Mbps to 300 Mbps (MCS0-MCS15, VHT 20/40)
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b: 1, 2, 5.5, 11 Mbps
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

Wi-Fi Antennas

2.4 GHz: 2× 4 dBi
5 GHz: 2× 5 dBi

Power sources

802.3at PoE, 48V/0.5A Passive PoE (PoE Adapter Included)

Power Consumption

EU: 12.5W (802.3at PoE or Passive PoE)
US: 14.7W (802.3at PoE or Passive PoE)

Dimension

• 280.4×106.5×56.8 mm (without antenna & mounting kit)

Mounting

Pole/Wall Mounting (Kits included)

Warranty

Limited Lifetime Warranty
