ACCESS POINT REYEE [RG-RAP6202(G)] WI-FI 5 AC1300 OUTDOOR OMNI-DIRECTIONAL

Product Specification

Overview

Reyee RG-RAP6202(G) Wi-Fi 5 AC1300 6 Wireless Access Point แบบติดตั้งภายนอกอาคาร มาตรฐาน ac กระจายสัญญาณรอบทิศทาง ความเร็ว 1267Mbps, Port Lan Gigabit รองรับ POE (ไม่มีในชุดอุปกรณ์), กันฝุ่นกันฝนมาตรฐาน IP68

พร้อม Ruijie Cloud License แบบ Lifetime

Wi-Fi Standards

Wi-Fi 5 (IEEE 802.11ac Wave2)
Wi-Fi 4(IEEE 802.11n)

RF Design

2.4 GHz, 2×2, MU-MIMO 5 GHz, 2×2, MU-MIMO

Max. Wi-Fi Speed

2.4 GHz: 400 Mbps
5 GHz: 867 Mbps

Antenna

4

Antenna Type

Built-In Omnidirectional

Antenna Gain

2.4 GHz: 3 dBi 5 GHz: 3 dBi

Transmit Power

EIRP
≤ 26 dBm(2.4GHz)
≤ 27 dBm(5GHz )
country-specific restrictions apply

Thailand:
2400 MHz~2483.5 MHz ≤ 20 dBm
5150 MHz~5350 MHz ≤ 23 dBm
5470 MHz~5725 MHz ≤ 25 dBm
5725 MHz~5850 MHz ≤ 30 dBm

Fixed Ports

2×10/100/1000 Base-T

Max. Clients

110

Recommended Clients

96

Max. SSIDs

8

Software Feature

WLAN Basic Features

SSID Hiding

Support

Power Adjustment

Support

Roaming

Layer 2 roaming
Layer 3 roaming

OFDMA

Support

Target wake time (TWT)*

Support

WMM

Support

Radar Signal Detection and Frequency Hopping

Support

WLAN Security

Security Mode

WPA-PSK, WPA2-PSK, WPA/WPA2-PSK;

Blacklist and Whitelist

Support

Enhanced User Experience

Wi-Fi Optimization

Support

Automatic RF adjustment via the platform

Support

User Isolation

Layer 2 user isolation

STA limit

Support

Removing Low-RSSI STAs

Support

Configuring STAs' RSSI Threshold

Support

Average Speed Threshold

Support

Adjusting Sending Rate of Beacon and Probe Response

Support

Syslog Recording Why Users Lose Connection

Support

Auto Channel and Power Adjustment on Cloud

Support

RSSI Threshold for STA Access

Support

Quick channel adjustment (auto channel selection)

Support

Networks

Network Access Mode

DHCP Client

VLAN

Support

System

Cloud Management

Support

App Management

Support

App Upgrade

Support

App Restart

Support

Scheduled Restart

Support

Local Upgrade

Support

Online Upgrade

Support

Factory Reset

Support

WLAN Features

Frequency Bandwidth

2.4 GHz: 20/40 MHz 5 GHz: 20/40/80 MHz

Recommended Wi-Fi Coverage Radius

2.4G 50m, 5G 150m

Max. Wi-Fi Coverage Radius

2.4G 100m, 5G 300m

Operation Frequency Bands

802.11b/g/n: 2.400 GHz to 2.483 GHz
802.11a/n/ac: 5.150 GHz to 5.350 GHz
802.11a/n/ac: 5.470 to 5.725 GHz , 5.725 to 5.850 GHz
country-specific restrictions apply

Receive Sensitivity

802.11b: -91 dBm(1Mbps)，-88 dBm(5.5Mbps)，-85 dBm(11Mbps)
802.11a/g: -89 dBm(6Mbps), -80 dBm(24Mbps), -76 dBm(36Mbps), -71dBm(54Mbps)
802.11n: -83 dBm@MCS0, -65 dBm@MCS7, -83 dBm@MCS8, -65 dBm@MCS15
802.11ac VHT20: -83 dBm(MCS0), -57 dBm(MCS9)
802.11ac VHT40: -79 dBm(MCS0), -57 dBm(MCS9)
802.11ac VHT80: -76 dBm(MCS0), -51 dBm(MCS9)

Physical

LED Indicator

3 x system LED indicator

Buttons

1 x Reset button

Dimensions (W x D x H)

200mm × 220mm × 166mm(Without Mounting Bracket)

Weight

1.0kg(Without Mounting Bracket)

Power

Power Supplies

IEEE 802.3at PoE DC 12V/1.5A (ไม่มี POE Injector/ DC Adapter ในชุดอุปกรณ์)

Power Consumption

≤ 13W

DC Port Dimensions

Outer Diameter: 5.5 mm Inner Diameter: 2.1 mm Length: 10 mm

Environmental

Operating Temperature

-30°C to 65°C

Storage Temperature

-40°C to 85°C

Operating Humidity

0% to 100% (Noncondensing)

Storage Humidity

0% to 100% (Noncondensing)

IP(Ingress Protection)

IP68

Port Surge

4 kV

MTBF

>250000H

ประกัน

3 ปี
